In the world of electrical and power distribution, the reliability and safety of connections are paramount. Medlon, a trusted name in power blade connector manufacturing, proudly presents the JYZ Series Standoff Insulators. These insulators are meticulously designed to offer superior performance, durability, and safety in various electrical applications. This article provides a detailed overview of the key specifications of the JYZ Series Standoff Insulators, highlighting why they are an excellent choice for your electrical insulation needs.

Overview of JYZ Series Standoff Insulators

Medlon's JYZ Series Standoff Insulators are engineered to provide high mechanical strength and excellent electrical insulation. These insulators are ideal for use in power distribution systems, switchgear, control panels, and various other electrical installations where reliable insulation and support are crucial.

Key Specifications

1. Material Composition

   • Insulator Body: Made from high-grade epoxy resin, the JYZ Series insulators offer excellent dielectric properties, mechanical strength, and resistance to moisture and chemicals. The epoxy resin ensures long-term durability and reliability in harsh environments.
   • Metal Insert: The insulators feature a threaded metal insert, typically made from brass or stainless steel, providing robust mechanical support and ensuring secure attachment to various components.

2. Electrical Properties

   • Dielectric Strength: The JYZ Series insulators have a dielectric strength of ≥20 kV/mm, ensuring superior insulation performance even under high voltage conditions.
   • Creepage Distance: With a creepage distance of ≥50 mm, these insulators provide effective protection against surface leakage currents, enhancing overall system safety.
   • Insulation Resistance: The insulation resistance of the JYZ Series is ≥500 MΩ, ensuring minimal leakage currents and maintaining electrical integrity over time.

3. Mechanical Properties

   • Tensile Strength: The insulators exhibit a tensile strength of ≥150 MPa, providing excellent resistance to mechanical stress and ensuring long-term stability and support.
   • Compression Strength: With a compression strength of ≥350 MPa, the JYZ Series insulators can withstand significant mechanical loads without deformation or damage.
   • Operating Temperature Range: Designed to perform in a wide range of temperatures, these insulators can operate effectively from -40°C to +120°C, making them suitable for various environmental conditions.

4. Dimensions and Mounting

   • Height: Available in various heights ranging from 30 mm to 150 mm, catering to different application needs and spacing requirements.
   • Diameter: The standard diameter options include 20 mm, 30 mm, and 50 mm, providing flexibility in design and installation.
   • Thread Size: The metal inserts are available with different thread sizes, such as M6, M8, and M10, ensuring compatibility with a wide range of mounting requirements.

5. Environmental Resistance

   • UV Resistance: The epoxy resin material used in the JYZ Series insulators is UV resistant, preventing degradation due to prolonged exposure to sunlight.
   • Chemical Resistance: These insulators are resistant to a variety of chemicals, including oils, acids, and alkalis, ensuring reliable performance in chemically aggressive environments.

   • Moisture Resistance: The high moisture resistance of the JYZ Series insulators ensures they maintain their electrical and mechanical properties even in humid conditions.


Applications

Medlon's JYZ Series Standoff Insulators are versatile and suitable for a wide range of applications, including:

• Power Distribution Systems: Providing reliable insulation and support for bus bars, conductors, and other components in power distribution networks.
• Switchgear and Control Panels: Ensuring safe and effective insulation in high voltage and control equipment.
• Telecommunications: Offering robust insulation solutions for telecom infrastructure and equipment.
• Renewable Energy Systems: Used in solar and wind power installations to ensure reliable electrical connections and insulation.

Conclusion

The JYZ Series Standoff Insulators by Medlon are designed to meet the highest standards of electrical insulation and mechanical support. With their superior material properties, excellent electrical and mechanical performance, and resistance to environmental factors, these insulators are the ideal choice for a wide range of applications. Trust Medlon for your power blade connector and insulation needs, and experience the reliability and performance that our products deliver.

For more information about the JYZ Series Standoff Insulators and to explore our comprehensive range of electrical components, visit our website or contact our expert support team. Medlon - Ensuring Reliability, One Connection at a Time.
